Cloudflare Tunnel as an alternative to Kubernetes ingress

Introduction

Kubernetes Ingress is the most popular way to expose Kubernetes resources publicly. However, in some cases, you might prefer not to use an Ingress—for example, if you want to avoid load balancer costs or lack a publicly accessible IP address. Cloudflare Tunnel offers an ideal solution for these scenarios.

Prerequisites

• A K8s cluster.
• Cloudflare Zero Trust.
• Cloudflare Tunnel client (cloudflared) installed.

Step-by-step

1. Log in to Cloudflare account using the cloudflared command

   cloudflared login


2. Create a tunnel

   cloudflared tunnel create TUNNEL_NAME

   Tunnel credentials written to /root/.cloudflared/c068bf40-4a63-4de5-9ba7-3a565d4eae40.json.


3. Create a secret to store the tunnel credentials

   With SealedSecret:

   kubectl -n K8S_NAMESPACE create secret generic tunnel-credentials --dry-run=client \
   --from-file=credentials.json=/root/.cloudflared/c068bf40-4a63-4de5-9ba7-3a565d4eae40.json \
   -o yaml | kubeseal --format=yaml > sealed-secret.yaml


   Or using a standard Kubernetes Secret:

   kubectl -n K8S_NAMESPACE create secret generic tunnel-credentials \
   --from-file=credentials.json=/root/.cloudflared/c068bf40-4a63-4de5-9ba7-3a565d4eae40.json


4. Choose you hostname and configure your DNS

   Suppose you want to expose your application at app.mydomain.com. In Cloudflare DNS, add a CNAME record named app pointing to your Cloudflare Tunnel hostname, e.g., c068bf40-4a63-4de5-9ba7-3a565d4eae40.cfargotunnel.com. You'll also need to configure the tunnel ingress with the desired hostname (app.mydomain.com) in the next step.

5. Deploy and configure cloudflared using Helm

   With FluxCD:

   apiVersion: helm.toolkit.fluxcd.io/v2
   kind: HelmRelease
   metadata:
     name: cloudflared
     namespace: K8S_NAMESPACE
   spec:
     interval: 24h
     chart:
       spec:
         chart: cloudflared
         version: '^0.1.1'
         sourceRef:
           kind: HelmRepository
           name: k8sonlab
           namespace: K8S_NAMESPACE
         interval: 24h
     values:
       cloudflare:
         tunnelName: TUNNEL_NAME
         tunnelId: c068bf40-4a63-4de5-9ba7-3a565d4eae40
         secretName: tunnel-credentials
         ingress:
           - hostname: app.mydomain.com
             service: http://app.K8S_NAMESPACE:3000
   ---
   apiVersion: source.toolkit.fluxcd.io/v1
   kind: HelmRepository
   metadata:
     name: k8sonlab
     namespace: usa-idl-prod
   spec:
     interval: 24h
     url: https://charts.ar80.eu


   Or using the Helm CLI:

   helm repo add k8sonlab https://charts.ar80.eu
   helm repo update

   helm install cloudflared k8sonlab/cloudflared \
     --version 0.1.1 \
     --namespace K8S_NAMESPACE \
     --create-namespace \
     --set cloudflare.tunnelName=TUNNEL_NAME \
     --set cloudflare.tunnelId=c068bf40-4a63-4de5-9ba7-3a565d4eae40 \
     --set cloudflare.secretName=tunnel-credentials \
     --set cloudflare.ingress[0].hostname=app.mydomain.com \
     --set cloudflare.ingress[0].service=http://app.K8S_NAMESPACE:3000


6. Verify

   You can visit app.mydomain.com to confirm that the tunnel is functioning properly.

Conclusion

Using Cloudflare Tunnel to expose your Kubernetes services is straightforward, simple, and secure. Additionally, you benefit from Cloudflare's features such as caching, CDN, and DDoS protection.
