High Availability Self-Hosted Plausible Analytics on Kubernetes

Introduction

There are several tutorials on installing Plausible Analytics on Kubernetes, but none of them explain how to achieve high availability. In this guide, I'll walk you through setting up Plausible Analytics with a highly available ClickHouse cluster and PostgreSQL cluster.

Prerequisites

• A Kubernetes cluster with at least three worker nodes.
• CloudNativePG - PostgreSQL Operator for Kubernetes installed.
• Altinity Kubernetes Operator for ClickHouse installed.
• cert-manager.io installed with a cluster issuer.

Step-by-step Guide

Note: This might only works with Plausible CE v2.1.3.

1. Create a plausible namespace:

   apiVersion: v1
   kind: Namespace
   metadata:
     name: plausible


   Save as namespace.yaml file and send to K8s:

   kubectl create -f namespace.yaml


2. ZooKeeper is required for ClickHouse cluster replication, deploy a HA ZooKeeper:

   ---
   apiVersion: policy/v1
   kind: PodDisruptionBudget
   metadata:
     name: zookeeper-pod-disruption-budget
     namespace: plausible
   spec:
     selector:
       matchLabels:
         app: zookeeper
     maxUnavailable: 1
   ---
   # Setup Service to provide access to Zookeeper for clients
   apiVersion: v1
   kind: Service
   metadata:
     name: zookeeper
     namespace: plausible
     labels:
       app: zookeeper
   spec:
     ports:
       - port: 2181
         name: client
       - port: 7000
         name: prometheus
     selector:
       app: zookeeper
       what: node
   ---
   # Setup Headless Service for StatefulSet
   apiVersion: v1
   kind: Service
   metadata:
     # DNS would be like zookeeper-0.zookeeper-headless
     name: zookeeper-headless
     namespace: plausible
     labels:
       app: zookeeper
   spec:
     ports:
       - port: 2181
         name: client
       - port: 2888
         name: server
       - port: 3888
         name: leader-election
     clusterIP: None
     selector:
       app: zookeeper
       what: node
   ---
   apiVersion: apps/v1
   kind: StatefulSet
   metadata:
     name: zookeeper
     namespace: plausible
   spec:
     selector:
       matchLabels:
         app: zookeeper
     serviceName: zookeeper-headless
     replicas: 3
     updateStrategy:
       type: RollingUpdate
     podManagementPolicy: Parallel
     template:
       metadata:
         labels:
           app: zookeeper
           what: node
         annotations:
           prometheus.io/port: '7000'
           prometheus.io/scrape: 'true'
       spec:
         affinity:
           podAntiAffinity:
             requiredDuringSchedulingIgnoredDuringExecution:
               - labelSelector:
                   matchExpressions:
                     - key: 'app'
                       operator: In
                       values:
                         - zookeeper
                 topologyKey: 'kubernetes.io/hostname'
         containers:
           - name: kubernetes-zookeeper
             imagePullPolicy: IfNotPresent
             image: 'docker.io/zookeeper:3.8.3'
             ports:
               - containerPort: 2181
                 name: client
               - containerPort: 2888
                 name: server
               - containerPort: 3888
                 name: leader-election
               - containerPort: 7000
                 name: prometheus
             # See those links for proper startup settings:
             # https://github.com/kow3ns/kubernetes-zookeeper/blob/master/docker/scripts/start-zookeeper
             # https://clickhouse.yandex/docs/en/operations/tips/#zookeeper
             # https://github.com/ClickHouse/ClickHouse/issues/11781
             command:
               - bash
               - -x
               - -c
               - |
                 SERVERS=3 &&
                 HOST=`hostname -s` &&
                 DOMAIN=`hostname -d` &&
                 CLIENT_PORT=2181 &&
                 SERVER_PORT=2888 &&
                 ELECTION_PORT=3888 &&
                 PROMETHEUS_PORT=7000 &&
                 ZOO_DATA_DIR=/var/lib/zookeeper/data &&
                 ZOO_DATA_LOG_DIR=/var/lib/zookeeper/datalog &&
                 {
                   echo "clientPort=${CLIENT_PORT}"
                   echo 'tickTime=2000'
                   echo 'initLimit=300'
                   echo 'syncLimit=10'
                   echo 'maxClientCnxns=2000'
                   echo 'maxTimeToWaitForEpoch=2000'
                   echo 'maxSessionTimeout=60000000'
                   echo "dataDir=${ZOO_DATA_DIR}"
                   echo "dataLogDir=${ZOO_DATA_LOG_DIR}"
                   echo 'autopurge.snapRetainCount=10'
                   echo 'autopurge.purgeInterval=1'
                   echo 'preAllocSize=131072'
                   echo 'snapCount=3000000'
                   echo 'leaderServes=yes'
                   echo 'standaloneEnabled=false'
                   echo '4lw.commands.whitelist=*'
                   echo 'metricsProvider.className=org.apache.zookeeper.metrics.prometheus.PrometheusMetricsProvider'
                   echo "metricsProvider.httpPort=${PROMETHEUS_PORT}"
                   echo "zookeeper.skipACL=true"
                 } > /conf/zoo.cfg &&
                 {
                   echo "zookeeper.root.logger=CONSOLE"
                   echo "zookeeper.console.threshold=INFO"
                   echo "log4j.rootLogger=\${zookeeper.root.logger}"
                   echo "log4j.appender.CONSOLE=org.apache.log4j.ConsoleAppender"
                   echo "log4j.appender.CONSOLE.Threshold=\${zookeeper.console.threshold}"
                   echo "log4j.appender.CONSOLE.layout=org.apache.log4j.PatternLayout"
                   echo "log4j.appender.CONSOLE.layout.ConversionPattern=%d{ISO8601} [myid:%X{myid}] - %-5p [%t:%C{1}@%L] - %m%n"
                 } > /conf/log4j.properties &&
                 echo 'JVMFLAGS="-Xms128M -Xmx1G -XX:ActiveProcessorCount=8 -XX:+AlwaysPreTouch -Djute.maxbuffer=8388608 -XX:MaxGCPauseMillis=50"' > /conf/java.env &&
                 if [[ $HOST =~ (.*)-([0-9]+)$ ]]; then
                     NAME=${BASH_REMATCH[1]}
                     ORD=${BASH_REMATCH[2]}
                 else
                     echo "Failed to parse name and ordinal of Pod"
                     exit 1
                 fi &&
                 mkdir -p ${ZOO_DATA_DIR} &&
                 mkdir -p ${ZOO_DATA_LOG_DIR} &&
                 export MY_ID=$((ORD+1)) &&
                 echo $MY_ID > $ZOO_DATA_DIR/myid &&
                 for (( i=1; i<=$SERVERS; i++ )); do
                     echo "server.$i=$NAME-$((i-1)).$DOMAIN:$SERVER_PORT:$ELECTION_PORT" >> /conf/zoo.cfg;
                 done &&
                 if [[ $SERVERS -eq 1 ]]; then
                     echo "group.1=1" >> /conf/zoo.cfg;
                 else
                     echo "group.1=1:2:3" >> /conf/zoo.cfg;
                 fi &&
                 chown -Rv zookeeper "$ZOO_DATA_DIR" "$ZOO_DATA_LOG_DIR" "$ZOO_LOG_DIR" "$ZOO_CONF_DIR" &&
                 zkServer.sh start-foreground
             readinessProbe:
               exec:
                 command:
                   - bash
                   - -c
                   - 'OK=$(echo ruok | nc 127.0.0.1 2181); if [[ "$OK" == "imok" ]]; then exit 0; else exit 1; fi'
               initialDelaySeconds: 10
               timeoutSeconds: 5
             livenessProbe:
               exec:
                 command:
                   - bash
                   - -c
                   - 'OK=$(echo ruok | nc 127.0.0.1 2181); if [[ "$OK" == "imok" ]]; then exit 0; else exit 1; fi'
               initialDelaySeconds: 10
               timeoutSeconds: 5
             volumeMounts:
               - name: zookeeper-data
                 mountPath: /var/lib/zookeeper
         securityContext:
           runAsUser: 1000
           fsGroup: 1000
     volumeClaimTemplates:
       - metadata:
           name: zookeeper-data
         spec:
           accessModes:
             - ReadWriteOnce
           resources:
             requests:
               storage: 1Gi


   Save as zookeeper.yaml file and send to K8s:

   kubectl create -f zookeeper.yaml


3. Deploy the HA ClickHouse cluster:

   apiVersion: 'clickhouse.altinity.com/v1'
   kind: 'ClickHouseInstallation'
   metadata:
     name: plausible
     namespace: plausible
   spec:
     configuration:
       users:
         plausible/password_sha256_hex: xxxyyy # printf 'YOUR_PASSWORD' | sha256sum
         plausible/networks/ip:
           - 0.0.0.0/0
       zookeeper:
         nodes:
           - host: zookeeper-0.zookeeper-headless.plausible.svc
           - host: zookeeper-1.zookeeper-headless.plausible.svc
           - host: zookeeper-2.zookeeper-headless.plausible.svc
       clusters:
         - name: 'cluster'
           templates:
             podTemplate: pod-template
           layout:
             shardsCount: 1
             replicasCount: 3
     templates:
       podTemplates:
         - name: pod-template
           spec:
             containers:
               - name: clickhouse
                 image: clickhouse/clickhouse-server:24.3
                 volumeMounts:
                   - name: clickhouse-data
                     mountPath: /var/lib/clickhouse
                   - name: clickhouse-log
                     mountPath: /var/log/clickhouse-server
       volumeClaimTemplates:
         - name: clickhouse-data
           spec:
             accessModes:
               - ReadWriteOnce
             resources:
               requests:
                 storage: 2Gi
         - name: clickhouse-log
           spec:
             accessModes:
               - ReadWriteOnce
             resources:
               requests:
                 storage: 2Gi


   Save as clickhouse.yaml file and send to K8s:

   kubectl create -f clickhouse.yaml


4. Deploy a HA PostgreSQL cluster:

   ---
   apiVersion: postgresql.cnpg.io/v1
   kind: Cluster
   metadata:
     name: postgresql-plausible
     namespace: plausible
   spec:
     # https://github.com/cloudnative-pg/postgres-containers/pkgs/container/postgresql
     # https://github.com/cloudnative-pg/postgis-containers/pkgs/container/postgis
     imageName: ghcr.io/cloudnative-pg/postgresql:17.0
     instances: 3
     postgresql:
       parameters:
         max_worker_processes: '60'
       pg_hba:
         - host all all all md5
     storage:
       size: 1Gi
     primaryUpdateMethod: switchover
     monitoring:
       enablePodMonitor: true
   ---
   apiVersion: postgresql.cnpg.io/v1
   kind: Pooler
   metadata:
     name: postgresql
     namespace: plausible
   spec:
     cluster:
       name: postgresql-plausible
     instances: 3
     type: rw
     pgbouncer:
       poolMode: session
       parameters:
         max_client_conn: '1000'
         default_pool_size: '10'


   Save as postgresql.yaml file and send to K8s:

   kubectl create -f postgresql.yaml


5. Provide the ENVs for the Plausible through ConfigMap and Secret:

   You can get the PostgreSQL password in the postgresql-plausible-app secret:

   kubectl -n plausible get secret postgresql-plausible-app -o jsonpath="{.data.password}" | base64 --decode


   You can create a K8s secret for storing plausible ENVs:

   export SECRET_KEY_BASE=$(openssl rand -base64 48)
   export TOTP_VAULT_KEY=$(openssl rand -base64 32)
   export DATABASE_URL='postgres://app:ToBeReplaced@postgresql.plausible:5432/app'
   export CLICKHOUSE_DATABASE_URL='http://default:ToBeReplaced@clickhouse-plausible.plausible:8123/default'
   export SMTP_USER_PWD='toBeReplaced'

   kubectl create secret generic --dry-run=client \
       plausible-env \
       --namespace='plausible' \
       --from-literal=SECRET_KEY_BASE=$SECRET_KEY_BASE \
       --from-literal=TOTP_VAULT_KEY=$TOTP_VAULT_KEY \
       --from-literal=DATABASE_URL=$DATABASE_URL \
       --from-literal=CLICKHOUSE_DATABASE_URL=$CLICKHOUSE_DATABASE_URL \
       --from-literal=SMTP_USER_PWD=$SMTP_USER_PWD \
       -o yaml


   Your final YAML file for the ENVs will looks like this:

   apiVersion: v1
   kind: ConfigMap
   metadata:
     name: plausible-env
     namespace: plausible
   data:
     BASE_URL: 'https://analytics.domain.com' # Update this
     DISABLE_REGISTRATION: 'invite_only'
     ENABLE_EMAIL_VERIFICATION: 'true'
     MAILER_NAME: 'Plausible Analytics'
     MAILER_EMAIL: 'plausible@analytics.domain.com' # Update this
     SMTP_HOST_ADDR: 'smtp.tem.scw.cloud' # Update this
     SMTP_USER_NAME: 'xxxxxxxx-aaaa-bbbb-cccc-yyyyyyyyyyyyy' # Update this
   ---
   apiVersion: v1
   data:
     CLICKHOUSE_DATABASE_URL: XXX
     DATABASE_URL: YYY
     SECRET_KEY_BASE: ZZZ
     SMTP_USER_PWD: AAA
     TOTP_VAULT_KEY: BBB
   kind: Secret
   metadata:
     creationTimestamp: null
     name: plausible-env
     namespace: plausible


   Save as env.yaml file and send to K8s:

   kubectl create -f env.yaml


6. Plausible doesn't natively support a highly available (HA) ClickHouse replication cluster. To enable this, we need to manually create the necessary Replicated tables on the ClickHouse cluster:

   CREATE TABLE default.location_data ON cluster '{cluster}'
   (
       `type` LowCardinality(String),
       `id` String,
       `name` String
   )
   ENGINE = ReplicatedMergeTree('/clickhouse/{cluster}/tables/{shard}/{database}/{table}', '{replica}')
   ORDER BY (type, id)
   SETTINGS index_granularity = 128
   COMMENT '2024-07-09';

   CREATE DICTIONARY default.location_data_dict ON cluster '{cluster}'
   (
       `type` String,
       `id` String,
       `name` String
   )
   PRIMARY KEY type, id
   SOURCE(CLICKHOUSE(TABLE location_data DB 'default'))
   LIFETIME(MIN 0 MAX 0)
   LAYOUT(COMPLEX_KEY_CACHE(SIZE_IN_CELLS 500000));

   CREATE TABLE default.sessions_v2 ON cluster '{cluster}'
   (
       `session_id` UInt64,
       `sign` Int8,
       `site_id` UInt64,
       `user_id` UInt64,
       `hostname` String CODEC(ZSTD(3)),
       `timestamp` DateTime CODEC(Delta(4), LZ4),
       `start` DateTime CODEC(Delta(4), LZ4),
       `is_bounce` UInt8,
       `entry_page` String CODEC(ZSTD(3)),
       `exit_page` String CODEC(ZSTD(3)),
       `pageviews` Int32,
       `events` Int32,
       `duration` UInt32,
       `referrer` String CODEC(ZSTD(3)),
       `referrer_source` String CODEC(ZSTD(3)),
       `country_code` LowCardinality(FixedString(2)),
       `screen_size` LowCardinality(String),
       `operating_system` LowCardinality(String),
       `browser` LowCardinality(String),
       `utm_medium` String CODEC(ZSTD(3)),
       `utm_source` String CODEC(ZSTD(3)),
       `utm_campaign` String CODEC(ZSTD(3)),
       `browser_version` LowCardinality(String),
       `operating_system_version` LowCardinality(String),
       `subdivision1_code` LowCardinality(String),
       `subdivision2_code` LowCardinality(String),
       `city_geoname_id` UInt32,
       `utm_content` String CODEC(ZSTD(3)),
       `utm_term` String CODEC(ZSTD(3)),
       `transferred_from` String,
       `entry_meta.key` Array(String) CODEC(ZSTD(3)),
       `entry_meta.value` Array(String) CODEC(ZSTD(3)),
       `exit_page_hostname` String CODEC(ZSTD(3)),
       `city` UInt32 ALIAS city_geoname_id,
       `country` LowCardinality(FixedString(2)) ALIAS country_code,
       `device` LowCardinality(String) ALIAS screen_size,
       `entry_page_hostname` String ALIAS hostname,
       `os` LowCardinality(String) ALIAS operating_system,
       `os_version` LowCardinality(String) ALIAS operating_system_version,
       `region` LowCardinality(String) ALIAS subdivision1_code,
       `screen` LowCardinality(String) ALIAS screen_size,
       `source` String ALIAS referrer_source,
       `country_name` String ALIAS dictGet('default.location_data_dict', 'name', ('country', country_code)),
       `region_name` String ALIAS dictGet('default.location_data_dict', 'name', ('subdivision', subdivision1_code)),
       `city_name` String ALIAS dictGet('default.location_data_dict', 'name', ('city', city_geoname_id)),
       `channel` LowCardinality(String),
       INDEX minmax_timestamp timestamp TYPE minmax GRANULARITY 1
   )
   ENGINE = ReplicatedVersionedCollapsingMergeTree('/clickhouse/{cluster}/tables/{shard}/{database}/{table}', '{replica}', sign, events)
   PARTITION BY toYYYYMM(start)
   PRIMARY KEY (site_id, toDate(start), user_id, session_id)
   ORDER BY (site_id, toDate(start), user_id, session_id)
   SAMPLE BY user_id
   SETTINGS index_granularity = 8192;


   CREATE TABLE default.ingest_counters ON cluster '{cluster}'
   (
       `event_timebucket` DateTime,
       `domain` LowCardinality(String),
       `site_id` Nullable(UInt64),
       `metric` LowCardinality(String),
       `value` UInt64
   )
   ENGINE = ReplicatedSummingMergeTree('/clickhouse/{cluster}/tables/{shard}/{database}/{table}', '{replica}', value)
   ORDER BY (domain, toDate(event_timebucket), metric, toStartOfMinute(event_timebucket))
   SETTINGS index_granularity = 8192;

   CREATE TABLE default.imported_visitors ON cluster '{cluster}'
   (
       `site_id` UInt64,
       `date` Date,
       `visitors` UInt64,
       `pageviews` UInt64,
       `bounces` UInt64,
       `visits` UInt64,
       `visit_duration` UInt64,
       `import_id` UInt64
   )
   ENGINE = ReplicatedMergeTree('/clickhouse/{cluster}/tables/{shard}/{database}/{table}', '{replica}')
   ORDER BY (site_id, date)
   SETTINGS index_granularity = 8192, replicated_deduplication_window = 0;

   CREATE TABLE default.imported_sources ON cluster '{cluster}'
   (
       `site_id` UInt64,
       `date` Date,
       `source` String,
       `utm_medium` String,
       `utm_campaign` String,
       `utm_content` String,
       `utm_term` String,
       `visitors` UInt64,
       `visits` UInt64,
       `visit_duration` UInt64,
       `bounces` UInt32,
       `import_id` UInt64,
       `pageviews` UInt64,
       `referrer` String,
       `utm_source` String
   )
   ENGINE = ReplicatedMergeTree('/clickhouse/{cluster}/tables/{shard}/{database}/{table}', '{replica}')
   ORDER BY (site_id, date, source)
   SETTINGS index_granularity = 8192, replicated_deduplication_window = 0;

   CREATE TABLE default.imported_pages ON cluster '{cluster}'
   (
       `site_id` UInt64,
       `date` Date,
       `hostname` String,
       `page` String,
       `visitors` UInt64,
       `pageviews` UInt64,
       `exits` UInt64,
       `time_on_page` UInt64,
       `import_id` UInt64,
       `visits` UInt64,
       `active_visitors` UInt64
   )
   ENGINE = ReplicatedMergeTree('/clickhouse/{cluster}/tables/{shard}/{database}/{table}', '{replica}')
   ORDER BY (site_id, date, hostname, page)
   SETTINGS index_granularity = 8192, replicated_deduplication_window = 0;

   CREATE TABLE default.imported_operating_systems ON cluster '{cluster}'
   (
       `site_id` UInt64,
       `date` Date,
       `operating_system` String,
       `visitors` UInt64,
       `visits` UInt64,
       `visit_duration` UInt64,
       `bounces` UInt32,
       `import_id` UInt64,
       `pageviews` UInt64,
       `operating_system_version` String
   )
   ENGINE = ReplicatedMergeTree('/clickhouse/{cluster}/tables/{shard}/{database}/{table}', '{replica}')
   ORDER BY (site_id, date, operating_system)
   SETTINGS index_granularity = 8192, replicated_deduplication_window = 0;

   CREATE TABLE default.imported_locations ON cluster '{cluster}'
   (
       `site_id` UInt64,
       `date` Date,
       `country` String,
       `region` String,
       `city` UInt64,
       `visitors` UInt64,
       `visits` UInt64,
       `visit_duration` UInt64,
       `bounces` UInt32,
       `import_id` UInt64,
       `pageviews` UInt64,
       `country_name` String ALIAS dictGet('default.location_data_dict', 'name', ('country', country)),
       `region_name` String ALIAS dictGet('default.location_data_dict', 'name', ('subdivision', region)),
       `city_name` String ALIAS dictGet('default.location_data_dict', 'name', ('city', city))
   )
   ENGINE = ReplicatedMergeTree('/clickhouse/{cluster}/tables/{shard}/{database}/{table}', '{replica}')
   ORDER BY (site_id, date, country, region, city)
   SETTINGS index_granularity = 8192, replicated_deduplication_window = 0;

   CREATE TABLE default.imported_exit_pages ON cluster '{cluster}'
   (
       `site_id` UInt64,
       `date` Date,
       `exit_page` String,
       `visitors` UInt64,
       `exits` UInt64,
       `import_id` UInt64,
       `pageviews` UInt64,
       `bounces` UInt32,
       `visit_duration` UInt64
   )
   ENGINE = ReplicatedMergeTree('/clickhouse/{cluster}/tables/{shard}/{database}/{table}', '{replica}')
   ORDER BY (site_id, date, exit_page)
   SETTINGS index_granularity = 8192, replicated_deduplication_window = 0;

   CREATE TABLE default.imported_entry_pages ON cluster '{cluster}'
   (
       `site_id` UInt64,
       `date` Date,
       `entry_page` String,
       `visitors` UInt64,
       `entrances` UInt64,
       `visit_duration` UInt64,
       `bounces` UInt32,
       `import_id` UInt64,
       `pageviews` UInt64
   )
   ENGINE = ReplicatedMergeTree('/clickhouse/{cluster}/tables/{shard}/{database}/{table}', '{replica}')
   ORDER BY (site_id, date, entry_page)
   SETTINGS index_granularity = 8192, replicated_deduplication_window = 0;

   CREATE TABLE default.imported_devices ON cluster '{cluster}'
   (
       `site_id` UInt64,
       `date` Date,
       `device` String,
       `visitors` UInt64,
       `visits` UInt64,
       `visit_duration` UInt64,
       `bounces` UInt32,
       `import_id` UInt64,
       `pageviews` UInt64
   )
   ENGINE = ReplicatedMergeTree('/clickhouse/{cluster}/tables/{shard}/{database}/{table}', '{replica}')
   ORDER BY (site_id, date, device)
   SETTINGS index_granularity = 8192, replicated_deduplication_window = 0;

   CREATE TABLE default.imported_custom_events ON cluster '{cluster}'
   (
       `site_id` UInt64,
       `import_id` UInt64,
       `date` Date,
       `name` String CODEC(ZSTD(3)),
       `link_url` String CODEC(ZSTD(3)),
       `path` String CODEC(ZSTD(3)),
       `visitors` UInt64,
       `events` UInt64
   )
   ENGINE = ReplicatedMergeTree('/clickhouse/{cluster}/tables/{shard}/{database}/{table}', '{replica}')
   ORDER BY (site_id, import_id, date, name)
   SETTINGS replicated_deduplication_window = 0, index_granularity = 8192;

   CREATE TABLE default.imported_browsers ON cluster '{cluster}'
   (
       `site_id` UInt64,
       `date` Date,
       `browser` String,
       `visitors` UInt64,
       `visits` UInt64,
       `visit_duration` UInt64,
       `bounces` UInt32,
       `import_id` UInt64,
       `pageviews` UInt64,
       `browser_version` String
   )
   ENGINE = ReplicatedMergeTree('/clickhouse/{cluster}/tables/{shard}/{database}/{table}', '{replica}')
   ORDER BY (site_id, date, browser)
   SETTINGS index_granularity = 8192, replicated_deduplication_window = 0;

   CREATE TABLE default.events_v2 ON cluster '{cluster}'
   (
       `timestamp` DateTime CODEC(Delta(4), LZ4),
       `name` LowCardinality(String),
       `site_id` UInt64,
       `user_id` UInt64,
       `session_id` UInt64,
       `hostname` String CODEC(ZSTD(3)),
       `pathname` String CODEC(ZSTD(3)),
       `referrer` String CODEC(ZSTD(3)),
       `referrer_source` String CODEC(ZSTD(3)),
       `country_code` FixedString(2),
       `screen_size` LowCardinality(String),
       `operating_system` LowCardinality(String),
       `browser` LowCardinality(String),
       `utm_medium` String CODEC(ZSTD(3)),
       `utm_source` String CODEC(ZSTD(3)),
       `utm_campaign` String CODEC(ZSTD(3)),
       `meta.key` Array(String) CODEC(ZSTD(3)),
       `meta.value` Array(String) CODEC(ZSTD(3)),
       `browser_version` LowCardinality(String),
       `operating_system_version` LowCardinality(String),
       `subdivision1_code` LowCardinality(String),
       `subdivision2_code` LowCardinality(String),
       `city_geoname_id` UInt32,
       `utm_content` String CODEC(ZSTD(3)),
       `utm_term` String CODEC(ZSTD(3)),
       `revenue_reporting_amount` Nullable(Decimal(18, 3)),
       `revenue_reporting_currency` FixedString(3),
       `revenue_source_amount` Nullable(Decimal(18, 3)),
       `revenue_source_currency` FixedString(3),
       `city` UInt32 ALIAS city_geoname_id,
       `country` LowCardinality(FixedString(2)) ALIAS country_code,
       `device` LowCardinality(String) ALIAS screen_size,
       `os` LowCardinality(String) ALIAS operating_system,
       `os_version` LowCardinality(String) ALIAS operating_system_version,
       `region` LowCardinality(String) ALIAS subdivision1_code,
       `screen` LowCardinality(String) ALIAS screen_size,
       `source` String ALIAS referrer_source,
       `country_name` String ALIAS dictGet('default.location_data_dict', 'name', ('country', country_code)),
       `region_name` String ALIAS dictGet('default.location_data_dict', 'name', ('subdivision', subdivision1_code)),
       `city_name` String ALIAS dictGet('default.location_data_dict', 'name', ('city', city_geoname_id)),
       `channel` LowCardinality(String)
   )
   ENGINE = ReplicatedMergeTree('/clickhouse/{cluster}/tables/{shard}/{database}/{table}', '{replica}')
   PARTITION BY toYYYYMM(timestamp)
   PRIMARY KEY (site_id, toDate(timestamp), name, user_id)
   ORDER BY (site_id, toDate(timestamp), name, user_id, timestamp)
   SAMPLE BY user_id
   SETTINGS index_granularity = 8192;

   CREATE TABLE default.schema_migrations ON cluster '{cluster}'
   (
       `version` Int64,
       `inserted_at` DateTime
   )
   ENGINE = ReplicatedMergeTree('/clickhouse/{cluster}/tables/{shard}/{database}/{table}', '{replica}')
   ORDER BY tuple();

   INSERT INTO "default"."schema_migrations" (version, inserted_at) VALUES
   (20200915070607,'2024-09-11 09:23:21'),
   (20200918075025,'2024-09-11 09:23:21'),
   (20201020083739,'2024-09-11 09:23:21'),
   (20201106125234,'2024-09-11 09:23:21'),
   (20210323130440,'2024-09-11 09:23:21'),
   (20210712214034,'2024-09-11 09:23:21'),
   (20211017093035,'2024-09-11 09:23:21'),
   (20211112130238,'2024-09-11 09:23:21'),
   (20220310104931,'2024-09-11 09:23:21'),
   (20220404123000,'2024-09-11 09:23:21'),
   (20220421161259,'2024-09-11 09:23:21'),
   (20220422075510,'2024-09-11 09:23:21'),
   (20230124140348,'2024-09-11 09:23:21'),
   (20230210140348,'2024-09-11 09:23:21'),
   (20230214114402,'2024-09-11 09:23:21'),
   (20230320094327,'2024-09-11 09:23:21'),
   (20230417104025,'2024-09-11 09:23:21'),
   (20230509124919,'2024-09-11 09:23:21'),
   (20231017073642,'2024-09-11 09:23:21'),
   (20240123142959,'2024-09-11 09:23:21'),
   (20240209085338,'2024-09-11 09:23:21'),
   (20240220123656,'2024-09-11 09:23:21'),
   (20240222082911,'2024-09-11 09:23:21'),
   (20240305085310,'2024-09-11 09:23:21'),
   (20240326134840,'2024-09-11 09:23:21'),
   (20240327085855,'2024-09-11 09:23:21'),
   (20240419133926,'2024-09-11 09:23:21'),
   (20240423094014,'2024-09-11 09:23:21'),
   (20240502115822,'2024-09-11 09:23:21'),
   (20240709181437,'2024-09-11 09:23:22'),
   (20240801091615,'2024-09-11 09:23:22'),
   (20240829092858,'2024-09-11 09:23:22');


   Connect to ClickHouse and execute the SQL query above using any preferred tool, such as DBeaver.

7. Deploy the Plausible with two or more replicas:

   apiVersion: apps/v1
   kind: Deployment
   metadata:
     name: plausible
     namespace: plausible
     annotations:
       reloader.stakater.com/auto: 'true'
     labels:
       app: plausible
   spec:
     replicas: 2
     selector:
       matchLabels:
         app: plausible
     template:
       metadata:
         namespace: plausible
         labels:
           app: plausible
       spec:
         initContainers:
           - name: migration
             image: ghcr.io/plausible/community-edition:v2.1.3
             command:
               - /bin/sh
               - -c
               - |
                 /entrypoint.sh db createdb && /entrypoint.sh db migrate
             envFrom:
               - secretRef:
                   name: plausible-env
               - configMapRef:
                   name: plausible-env
         containers:
           - name: plausible
             image: ghcr.io/plausible/community-edition:v2.1.3
             ports:
               - containerPort: 8000
             envFrom:
               - secretRef:
                   name: plausible-env
               - configMapRef:
                   name: plausible-env


   Save as depl.yaml file and send to K8s:

   kubectl create -f depl.yaml


8. Configure service and ingress for Plausible:

   ---
   apiVersion: v1
   kind: Service
   metadata:
     name: plausible
     namespace: plausible
   spec:
     selector:
       app: plausible
     ports:
       - protocol: TCP
         port: 8000
         targetPort: 8000
   ---
   apiVersion: networking.k8s.io/v1
   kind: Ingress
   metadata:
     name: plausible
     namespace: plausible
     annotations:
       cert-manager.io/cluster-issuer: letsencrypt-cluster-issuer
   spec:
     tls:
       - hosts:
           - analytics.domain.com # Update this
         secretName: plausible-tls
     rules:
       - host: analytics.domain.com
         http:
           paths:
             - path: /
               pathType: Prefix
               backend:
                 service:
                   name: plausible
                   port:
                     number: 8000


   Save as ingress-service.yaml file and send to K8s:

   kubectl create -f ingress-service.yaml


Verify

Once configured correctly, the following result will be displayed:

kubectl -n plausible get pods
NAME                          READY   STATUS    RESTARTS      AGE
chi-plausible-cluster-0-0-0   1/1     Running   0             24h
chi-plausible-cluster-0-1-0   1/1     Running   0             24h
chi-plausible-cluster-0-2-0   1/1     Running   0             24h
plausible-6cc78d59bb-56wjj    1/1     Running   2 (24h ago)   24h
plausible-6cc78d59bb-kl6sf    1/1     Running   1 (24h ago)   24h
postgresql-7968d465bd-87gx4   1/1     Running   0             24h
postgresql-7968d465bd-hlrdj   1/1     Running   0             24h
postgresql-7968d465bd-wj4ln   1/1     Running   0             24h
postgresql-plausible-1        1/1     Running   0             24h
postgresql-plausible-2        1/1     Running   0             24h
postgresql-plausible-3        1/1     Running   0             24h
zookeeper-0                   1/1     Running   1 (22h ago)   24h
zookeeper-1                   1/1     Running   0             24h
zookeeper-2                   1/1     Running   0             24h

You can now access to analytics.domain.com and create your Plausible account.

Conclusion

By following these steps, you now have a production-grade Plausible Analytics setup running on your Kubernetes cluster. I've been running my own Plausible in my cluster, and it has performed well without any downtime, even during Kubernetes node maintenance/restating.

References

• Plausible Community Edition.
• Altinity Kubernetes Operator for ClickHouse®.
• CloudNativePG - PostgreSQL Operator for Kubernetes.
