Introduction

The Argon EON Pi NAS is a NAS (network-attached storage) solution designed specifically for use with the Raspberry Pi 4. In this tutorial, I will show you how to partition and mount the hard drives and set up a K8s cluster for your Argon EON Pi NAS.

Prerequisites

  • Argon EON Pi NAS with Raspberry Pi 4.
  • At least one hard drive installed.
  • Ubuntu Server 24.04 LTS image installed on a Raspberry Pi.
  • Basic knowledge of Kubernetes.

Step-by-step Guide

I am using Kubeadm and CRI-O to set up the K8s cluster, but you can use whatever methods and container runtime you prefer.

  1. Update the system and install Argon EON:

    apt update && apt upgrade -y
curl https://download.argon40.com/argoneon.sh | bash

  2. Check the hard drives:

    lsblk
NAME        MAJ:MIN RM   SIZE RO TYPE MOUNTPOINTS
loop0         7:0    0  33.7M  1 loop /snap/snapd/21467
loop1         7:1    0  33.7M  1 loop /snap/snapd/21761
sda           8:0    0 931.5G  0 disk
sdb           8:16   0 931.5G  0 disk
sdc           8:32   0 931.5G  0 disk
sdd           8:48   0 931.5G  0 disk
mmcblk0     179:0    0  59.7G  0 disk
├─mmcblk0p1 179:1    0   512M  0 part /boot/firmware
└─mmcblk0p2 179:2    0  59.2G  0 part /

  3. Create filesystems for the hard drives:

    parted -s /dev/sda mklabel gpt
parted -s /dev/sdb mklabel gpt
parted -s /dev/sdc mklabel gpt
parted -s /dev/sdd mklabel gpt
parted -s /dev/sda unit mib mkpart primary 0% 100%
parted -s /dev/sdb unit mib mkpart primary 0% 100%
parted -s /dev/sdc unit mib mkpart primary 0% 100%
parted -s /dev/sdd unit mib mkpart primary 0% 100%
mkfs.ext4 /dev/sda1
mkfs.ext4 /dev/sdb1
mkfs.ext4 /dev/sdc1
mkfs.ext4 /dev/sdd1

  4. Mount the hard drives to the mnt folder:

    mkdir /mnt/sda /mnt/sdb /mnt/sdc /mnt/sdd
echo >> /etc/fstab
echo "UUID=$(blkid -s UUID -o value /dev/sda1) /mnt/sda ext4 defaults,noatime,nofail 0 0" >> /etc/fstab
echo "UUID=$(blkid -s UUID -o value /dev/sdb1) /mnt/sdb ext4 defaults,noatime,nofail 0 0" >> /etc/fstab
echo "UUID=$(blkid -s UUID -o value /dev/sdc1) /mnt/sdc ext4 defaults,noatime,nofail 0 0" >> /etc/fstab
echo "UUID=$(blkid -s UUID -o value /dev/sdd1) /mnt/sdd ext4 defaults,noatime,nofail 0 0" >> /etc/fstab
systemctl daemon-reload
mount /mnt/sda
mount /mnt/sdb
mount /mnt/sdc
mount /mnt/sdd

  5. Enable overlay and br_netfilter modules:

    sudo modprobe br_netfilter
sudo modprobe overlay

cat <<EOF | sudo tee /etc/modules-load.d/k8s.conf
br_netfilter
overlay
EOF

cat <<EOF | sudo tee /etc/sysctl.d/k8s.conf
net.bridge.bridge-nf-call-iptables  = 1
net.bridge.bridge-nf-call-ip6tables = 1
net.ipv4.ip_forward                 = 1
net.ipv6.conf.all.forwarding        = 1
EOF

sudo sysctl --system

  6. Install cri-o, kubelet, kubeadm and kubectl:

    KUBERNETES_VERSION=v1.30
CRIO_VERSION=v1.30

curl -fsSL https://pkgs.k8s.io/core:/stable:/$KUBERNETES_VERSION/deb/Release.key |
gpg --dearmor -o /etc/apt/keyrings/kubernetes-apt-keyring.gpg

echo "deb [signed-by=/etc/apt/keyrings/kubernetes-apt-keyring.gpg] https://pkgs.k8s.io/core:/stable:/$KUBERNETES_VERSION/deb/ /" |
tee /etc/apt/sources.list.d/kubernetes.list

curl -fsSL https://pkgs.k8s.io/addons:/cri-o:/stable:/$CRIO_VERSION/deb/Release.key |
gpg --dearmor -o /etc/apt/keyrings/cri-o-apt-keyring.gpg

echo "deb [signed-by=/etc/apt/keyrings/cri-o-apt-keyring.gpg] https://pkgs.k8s.io/addons:/cri-o:/stable:/$CRIO_VERSION/deb/ /" |
tee /etc/apt/sources.list.d/cri-o.list

apt-get update
apt-get install -y cri-o kubelet kubeadm kubectl
apt-mark hold kubelet kubectl cri-o

systemctl start crio.service

  7. Create the init config file init-config.yaml:

    apiVersion: kubeadm.k8s.io/v1beta3
kind: ClusterConfiguration
controlPlaneEndpoint: 'your.hostname.com:6443'
etcd:
  local:
    extraArgs:
      listen-metrics-urls: http://0.0.0.0:2381
controllerManager:
  extraArgs:
    bind-address: '0.0.0.0'
scheduler:
  extraArgs:
    bind-address: '0.0.0.0'
networking:
  podSubnet: 192.168.0.0/16
  serviceSubnet: 10.96.0.0/16
apiServer:
  certSANs:
    - 'your.hostname.com'
    - { NODE_PRIVATE_IP4 }
---
apiVersion: kubeadm.k8s.io/v1beta3
kind: InitConfiguration
localAPIEndpoint:
  advertiseAddress: { NODE_PRIVATE_IP4 }
  bindPort: 6443
nodeRegistration:
  kubeletExtraArgs:
    node-ip: { NODE_PRIVATE_IP4, NODE_PRIVATE_IP6 }
---
apiVersion: kubelet.config.k8s.io/v1beta1
kind: KubeletConfiguration
serverTLSBootstrap: true
---
apiVersion: kubeproxy.config.k8s.io/v1alpha1
kind: KubeProxyConfiguration
metricsBindAddress: '0.0.0.0:10249'

  8. Bootstrap the K8s cluster:

    sudo kubeadm init --config=init-config.yaml

  9. Allow scheduling of Pods on the control plane:

    kubectl taint nodes --all node-role.kubernetes.io/control-plane-

  10. Install Calico operator and CRDs:

    kubectl create -f https://raw.githubusercontent.com/projectcalico/calico/v3.28.1/manifests/tigera-operator.yaml

  11. Install Calico by applying the custom-resources file:

    kubectl create -f https://raw.githubusercontent.com/projectcalico/calico/v3.28.1/manifests/custom-resources.yaml

Conclusion

You now have a K8s cluster running in your Argon EON Pi NAS. You can continue installing storage solutions such as Ceph and Nextcloud.
