Self-host Ente Photos on Kubernetes with S3 storage

Introduction

Ente Photos is a self-hosted photo backup and gallery application. It has two main parts: the Ente server, also known as Museum, and the Ente web apps. Museum talks to PostgreSQL and object storage, while the web container exposes the Photos, Accounts, Albums, Auth, Cast, Locker, Embed, Paste, and Memories frontends.

In this guide, we will deploy Ente Photos on Kubernetes using PostgreSQL, S3-compatible object storage, cert-manager, Sealed Secrets, and Ingress. The manifests are based on a working Kustomize layout, but the domains, secrets, bucket names, and admin IDs are placeholders so you can adapt them safely.

Prerequisites

A running Kubernetes cluster.
kubectl access to the cluster.
Kustomize support through kubectl apply -k or Flux.
cert-manager with a ClusterIssuer named letsencrypt.
Sealed Secrets controller and kubeseal.
PostgreSQL database reachable from the ente namespace.
S3-compatible object storage bucket for Ente uploads.
DNS records for the Ente API and web hosts.

Step-by-step

Create a working directory for the manifests:
bash
```
mkdir -p ente
cd ente
```
Create namespace.yaml. Keeping Ente in its own namespace makes secrets, ingresses, and application resources easier to manage:
yaml
```
---
apiVersion: v1
kind: Namespace
metadata:
  name: ente
```
Create the PostgreSQL database and user. The Kubernetes manifests below expect Museum to connect to a database named ente with a user named ente:
sql
```
CREATE DATABASE ente;
CREATE USER ente WITH PASSWORD 'change-me';
GRANT ALL PRIVILEGES ON DATABASE ente TO ente;
```
If you use CloudNativePG or another operator, create the database and user with that operator instead. The important part is that the final hostname, database name, username, and password match museum.yaml and credentials.yaml.

Create a local credentials.yaml file. This file is mounted into the Ente server container at /credentials/credentials.yaml.

yaml

key:
  encryption: REPLACE_WITH_BASE64_32_BYTES
  hash: REPLACE_WITH_BASE64_64_BYTES
jwt:
  secret: REPLACE_WITH_BASE64_32_BYTES
smtp:
  host: smtp.example.com
  port: 465
  username: ente@example.com
  password: REPLACE_WITH_SMTP_PASSWORD
  email: ente@example.com
  sender-name: Ente
  encryption: ssl
s3:
  b2-eu-cen:
    are_local_buckets: false
    use_path_style_urls: true
    key: REPLACE_WITH_S3_ACCESS_KEY
    secret: REPLACE_WITH_S3_SECRET_KEY
    endpoint: https://s3.example.com
    region: us-east-1
    bucket: ente
db:
  password: REPLACE_WITH_POSTGRES_PASSWORD

You can generate base64 secrets like this:

bash

openssl rand -base64 32
openssl rand -base64 64

Seal the Ente credentials. Do not commit the plain credentials.yaml file:

bash

kubectl -n ente create secret generic ente-credentials \
  --from-file=credentials.yaml \
  --dry-run=client -o yaml | kubeseal --format yaml > ente-cred.yaml

If another manifest or database operator expects a separate PostgreSQL password Secret, create it the same way:

bash

export PASSWORD=REPLACE_WITH_POSTGRES_PASSWORD
kubectl -n ente create secret generic postgres-credentials \
  --from-literal=password=$PASSWORD \
  --dry-run=client -o yaml | kubeseal --format yaml > postgres-cred.yaml

In the manifests below, Museum reads the database password from credentials.yaml, so postgres-cred.yaml is optional unless you adapt the deployment to use it directly.

Create cert.yaml. This example uses one wildcard certificate for the API and web hosts:

yaml

---
apiVersion: cert-manager.io/v1
kind: Certificate
metadata:
  name: ente
  namespace: ente
spec:
  secretName: ente-tls
  issuerRef:
    name: letsencrypt
    kind: ClusterIssuer
  dnsNames:
    - photos.example.com
    - '*.photos.example.com'

Create server.depl.yaml. The server container reads the credentials file from a Secret and the Museum config from a ConfigMap:

yaml

---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: ente-server
  namespace: ente
  annotations:
    reloader.stakater.com/auto: 'true'
  labels:
    app: ente-server
spec:
  replicas: 1
  strategy:
    type: RollingUpdate
    rollingUpdate:
      maxUnavailable: 1
      maxSurge: 0
  selector:
    matchLabels:
      app: ente-server
  template:
    metadata:
      labels:
        app: ente-server
    spec:
      containers:
        - name: ente-server
          image: ghcr.io/ente/server:0137a0c754ac0fe4f2c4c7421727c349327eb990
          ports:
            - containerPort: 8080
          env:
            - name: ENTE_CREDENTIALS_FILE
              value: /credentials/credentials.yaml
            - name: ENTE_MUSEUM_CONFIG_FILE
              value: /museum.yaml
          volumeMounts:
            - name: ente-server-conf
              mountPath: /museum.yaml
              subPath: museum.yaml
              readOnly: true
            - name: ente-credentials
              mountPath: /credentials
              readOnly: true
      volumes:
        - name: ente-server-conf
          configMap:
            name: ente-server-conf
            items:
              - key: museum.yaml
                path: museum.yaml
        - name: ente-credentials
          secret:
            secretName: ente-credentials
            items:
              - key: credentials.yaml
                path: credentials.yaml
---
apiVersion: v1
kind: Service
metadata:
  name: ente-server
  namespace: ente
  labels:
    app: ente-server
spec:
  type: ClusterIP
  selector:
    app: ente-server
  ports:
    - name: http
      port: 8080
      targetPort: 8080
---
apiVersion: v1
kind: ConfigMap
metadata:
  name: ente-server-conf
  namespace: ente
data:
  museum.yaml: |
    db:
      host: "cluster-rw.postgresql"
      port: 5432
      name: "ente"
      user: "ente"

    apps:
      public-albums: "https://albums.photos.example.com"
      embed-albums: "https://embed.photos.example.com"
      public-locker: "https://locker.photos.example.com"
      public-paste: "https://paste.photos.example.com"
      cast: "https://cast.photos.example.com"
      accounts: "https://accounts.photos.example.com"
      public-memories: "https://memories.photos.example.com"

    space:
      assets:
        primaryBucket: b2-eu-cen

    internal:
      disable-registration: false
      admins: []

Create web.depl.yaml. The Ente web image exposes several frontends from one container. Each frontend gets a named Service port:

yaml

---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: ente-web
  namespace: ente
  annotations:
    reloader.stakater.com/auto: 'true'
  labels:
    app: ente-web
spec:
  replicas: 1
  selector:
    matchLabels:
      app: ente-web
  template:
    metadata:
      labels:
        app: ente-web
    spec:
      containers:
        - name: ente-web
          image: ghcr.io/ente/web:062c7066883b37978b6dea7b7703d4efc5f13351
          ports:
            - containerPort: 3000
            - containerPort: 3001
            - containerPort: 3002
            - containerPort: 3003
            - containerPort: 3004
            - containerPort: 3005
            - containerPort: 3006
            - containerPort: 3008
            - containerPort: 3009
            - containerPort: 3010
          env:
            - name: ENTE_API_ORIGIN
              value: https://api.photos.example.com
---
apiVersion: v1
kind: Service
metadata:
  name: ente-web
  namespace: ente
  labels:
    app: ente-web
spec:
  type: ClusterIP
  selector:
    app: ente-web
  ports:
    - name: photos
      port: 3000
      targetPort: 3000
    - name: accounts
      port: 3001
      targetPort: 3001
    - name: albums
      port: 3002
      targetPort: 3002
    - name: auth
      port: 3003
      targetPort: 3003
    - name: cast
      port: 3004
      targetPort: 3004
    - name: public-locker
      port: 3005
      targetPort: 3005
    - name: embed
      port: 3006
      targetPort: 3006
    - name: paste
      port: 3008
      targetPort: 3008
    - name: locker
      port: 3009
      targetPort: 3009
    - name: memories
      port: 3010
      targetPort: 3010

Create ingress.yaml. The API host points to ente-server, and the web hosts point to the matching named ports on ente-web:

yaml

---
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: ente-server
  namespace: ente
spec:
  tls:
    - hosts:
        - api.photos.example.com
      secretName: ente-tls
  rules:
    - host: api.photos.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: ente-server
                port:
                  number: 8080
---
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: ente-web
  namespace: ente
spec:
  tls:
    - hosts:
        - photos.example.com
        - accounts.photos.example.com
        - albums.photos.example.com
        - auth.photos.example.com
        - cast.photos.example.com
        - locker.photos.example.com
        - embed.photos.example.com
        - paste.photos.example.com
        - memories.photos.example.com
      secretName: ente-tls
  rules:
    - host: photos.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: ente-web
                port:
                  name: photos
    - host: accounts.photos.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: ente-web
                port:
                  name: accounts
    - host: albums.photos.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: ente-web
                port:
                  name: albums
    - host: auth.photos.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: ente-web
                port:
                  name: auth
    - host: cast.photos.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: ente-web
                port:
                  name: cast
    - host: locker.photos.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: ente-web
                port:
                  name: public-locker
    - host: embed.photos.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: ente-web
                port:
                  name: embed
    - host: paste.photos.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: ente-web
                port:
                  name: paste
    - host: memories.photos.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: ente-web
                port:
                  name: memories

Create kustomization.yaml:

yaml

apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization
resources:
  - namespace.yaml
  - cert.yaml
  - ente-cred.yaml
  - ingress.yaml
  - web.depl.yaml
  - server.depl.yaml

The plain credentials.yaml file is only an input for kubeseal. Do not add it to kustomization.yaml.

Deploy Ente Photos:
bash
```
kubectl apply -k .
```

Verify the rollout:

bash

kubectl -n ente get pods
kubectl -n ente get svc
kubectl -n ente get ingress
kubectl -n ente get certificate

Check the server logs if the API does not start:

bash

kubectl -n ente logs deploy/ente-server

Create your first user from the web UI, then add the user ID as an admin if you want to keep registration disabled. Query users from PostgreSQL:
sql
```
SELECT id, email FROM users;
```
Then update the internal.admins list in museum.yaml:
yaml
```
internal:
  disable-registration: true
  admins:
    - 1234567890123456
```
Apply the updated ConfigMap:
bash
```
kubectl apply -k .
kubectl -n ente rollout restart deploy/ente-server
```
Remove the default 10 GB subscription quota. On a self-hosted Ente instance, storage quota and account validity can be increased with the Ente CLI. First, make sure the admin user's ID is listed in internal.admins in museum.yaml, then restart Museum:
yaml
```
internal:
  disable-registration: true
  admins:
    - 1234567890123456
```
bash
```
kubectl apply -k .
kubectl -n ente rollout restart deploy/ente-server
```
Configure the Ente CLI to talk to your self-hosted API endpoint. The CLI reads config.yaml from ~/.ente, from ENTE_CLI_CONFIG_DIR, or from the directory where the CLI is running:
yaml
```
endpoint:
  api: https://api.photos.example.com
```
Add the admin account to the CLI:
bash
```
ente account add
```
Then remove the 10 GB quota for the target user:
bash
```
ente admin update-subscription \
  -a admin@example.com \
  -u user@example.com \
  --no-limit
```
Replace admin@example.com with the whitelisted admin email, and replace user@example.com with the registered user whose quota you want to update. The target user must already exist and must have completed email verification.

If you need to run the CLI from inside the Museum container, set the CLI secrets path before running the command:
bash
```
export ENTE_CLI_SECRETS_PATH=./secrets.txt
```
To turn unlimited storage off later, run the same command with --no-limit False, then use ente admin update-subscription --help to choose the storage and validity values you want.

Conclusion

You now have Ente Photos running on Kubernetes with the web apps behind Ingress, Museum behind a separate API host, credentials stored as a Sealed Secret, PostgreSQL for metadata, and S3-compatible object storage for uploads.

Before using it for real photos, test registration, login, uploads, album sharing, email delivery, and object storage backups. Also keep the plain credentials.yaml out of Git and back up your PostgreSQL database and S3 bucket.
